SENNHEISER XSW 1-825 DUAL-B HANDHELD MICROPHONE

XS Wireless 1 DUAL is a 2-channel wireless system for singers and presenters. Designed with ease of use in mind, these analog UHF systems feature a sleek dual-channel receiver with built-in antennas and the streamlined interface from Sennheiser’s popular XS Wireless 1 series.

• Excellent live sound featuring Sennheiser’s renowned evolution microphone capsules
• Antenna-switching 2-channel diversity reception
• Integrated antennas
• Automatic frequency management and synchronization via remote channel for easy setup
• Selectable UHF frequencies within a large bandwidth
• Up to 10 compatible channels

  System

  • Frequency range

    614–638 MHz

  • Dimensions

    Ø 48 x L 180 mm

  • Connector

    XLR-3

  • Frequency response

    55 – 16,000 Hz

  • THD, total harmonic distortion

    ≤ 0.9%

  • Transducer principle

    dynamic

  • Weight

    330 g (0.73 lbs)

  • Pick-up pattern

    cardioid

  • Nominal impedance

    300 Ω (at 1 kHz)

  • Min. terminating impedance

    1 kΩ

  • Storage temperature

    –20°C to +70°C

  • Operating temperature

    0°C to +40°C

  • Signal-to-noise ratio

    ≥ 103 dBA

  • Switching bandwidth

    Up to 24 MHz

  • Modulation

    Wideband FM

  • Frequency

    80 factory presets (8 banks of 10 channels each)

  • Sensitivity

    1.8 mV/Pa (free field, no load at 1 kHz)

  • Synchronization

    Transmitter: 2.4 GHz, low power OQPSK (only active during synchronization)

  • Temperature Range

    0 °C … +40 °C (+32 °F … +104 °F)

  • Frequency range

  • Frequency response

  EM-XSW 1 DUAL

  • Dimensions

    approx. 320 x 126.5 x 42 mm

  • Weight

    approx. 620 g

  • Power supply

    12 V DC nom. / 300 mA

  • Output voltage

    (at peak deviation, 1 kHz AF) 1/4“ (6.3 mm) socket (unbalanced): +6 dBu

  • Housing

    Rugged ABS housing

  • Sensitivity

    < 3 μV at 52 dB(A) rms S/N (at peak deviation)

  • Squelch

    Adjustable from 3 dBμV to 28 dBμV

  • AF frequency response

    50 to 16,000 Hz (–3 dB)

  • Audio adjustment range

    45 dB, adjustable in 5 dB steps

  • Line / Mic level

    20 dB, switchable

  • Receiver Principle

    Double superheterodyne

  • Diversity principle

    Antenna switching diversity via internal antennas

  SKM 825-XSW / SKM 835-XSW

  • Dimensions

    Approx. 260 x 50 mm

  • Microphone

    Dynamic

  • Weight

    Approx. 245 g

  • Pick-up pattern

    Cardioid

  • RF output power

    10 mW

  • Operating time

    Approx. 10 hrs

  • Power supply

    2 AA size batteries, 1.5 V

  • Housing

    Rugged ABS housing

  • Sensitivity

    0 to -30 dB, adjustable in 10 dB steps

  • Input sensitivity

    1.5 mV / Pa

  • AF frequency response

    80-16,000 Hz

  Buy the Sennheiser XSW 1-825 Dual-B Handheld Microphone at AudioStoreDubai.com.
  The Sennheiser XSW 1-825 Dual-B is a reliable wireless microphone system designed for performers, presenters, and musicians who demand clear sound and easy setup. Featuring two high-quality handheld transmitters with dynamic e825 capsules, this system delivers warm, detailed vocals and outstanding feedback rejection—ideal for live performances, events, and public speaking. With its intuitive one-touch scanning and synchronization, setup is fast and hassle-free. The robust receiver ensures stable UHF transmission and crisp, interference-free audio across a wide range. Perfect for stages, conferences, and worship venues, the XSW 1-825 Dual-B combines professional performance with Sennheiser’s legendary quality. Order now from AudioStoreDubai.com for fast delivery across Dubai, Abu Dhabi, and Sharjah.
